ITC - T-77240Z, 240W 8-Zone Rack Mount IP Amplifier

Features

- Rack mount IP amplifier with independent 8-zone management

- 240W rated power with 100V constant-voltage speaker output

- Standard 19-inch rack design with black aluminum panel

- 3.4-inch industrial LCD display for clear operating status information

- Infrared remote control for playback and pause operation

- Embedded computer technology with DSP audio processing

- Built-in 1-channel network hardware audio decoding module

- Supports TCP/IP and UDP network protocols

- Supports 16-bit CD-quality network audio transmission

- 8 independently controlled zones with 100V audio outputs

- Supports paging to individual zones, zone groups or all zones simultaneously

- Supports scheduled tasks for individual zones or zone groups

- Supports alarm-triggered tasks for selected zones or zone groups

- Supports real-time audio file playback to selected zones

- 1 MIC input with independent volume control

- 1 AUX input with independent volume control

- Independent treble and bass adjustment controls

- Supports local paging operation without a network connection

- 1 EMC emergency audio input with highest priority

- 1 auxiliary audio output for connection to an external power amplifier

- Intelligent power management with automatic amplifier standby

- Automatically powers the amplifier on when an audio signal is detected

- Supports programmable amplifier pre-power-on through IP software

- Built-in three-level audio priority management

- EMC input has the highest priority

- Network alarm signals take priority over MIC, AUX and network background music

- MIC input takes priority over AUX and network background music

- AUX and network background music operate at the same priority level

- Supports preset audio attenuation and background accompaniment functions

- Status indicators for level, protection and standby operation

- Standby power consumption below 10W

- Compatible with multiple network structures including routers, switches, gateways and Internet networks

- Digital network architecture enables flexible system expansion over long distances

- Supports remote terminal hardware upgrades for simplified maintenance

Specifications

- Brand: ITC

- Model: T-77240Z

- Type: 8-Zone Rack Mount IP Amplifier

- Rated Power: 240W

- Number of Zones: 8 independently controlled zones

- Speaker Output: 100V constant-voltage output

- Network Interface: Standard RJ45 input

- Transmission Rate: 100 Mbps

- Supported Protocols: TCP/IP, UDP

- Audio Format: MP3

- Audio Quality: 16-bit CD sound quality

- Sampling Rate: 8 kHz to 48 kHz

- EMC Input Sensitivity: 775 mV, unbalanced

- AUX Input Sensitivity: 350 mV, unbalanced

- MIC Input Sensitivity: 5 mV, unbalanced

- AUX Output Level: 1000 mV, 2 RCA outputs

- AUX Output Impedance: 470 Ω

- Treble Adjustment Range: ±10 dB

- Bass Adjustment Range: ±10 dB

- Power Consumption: 370W

- Standby Power Consumption: <10W

- Frequency Response: 80 Hz to 16 kHz, +1/-3 dB

- Total Harmonic Distortion: ≤1%

- Signal-to-Noise Ratio: >65 dB

- Circuit Protection: DC output, overload, overtemperature and short-circuit protection

- Operating Temperature: 5°C to 40°C

- Operating Humidity: 20% to 80% RH, non-condensing

- Power Supply: ~220V, 50Hz

- Installation: Standard 19-inch rack mount

- Dimensions: 484 × 359 × 132 mm

- Weight: 13.7 kg
