Bosch - LC2-PC60G6-10, 60W 10-Inch Premium-Sound Ceiling Subwoofer

Features

- Flush-mounted ceiling subwoofer

- 10-inch low-frequency loudspeaker

- High-excursion driver for extended bass reproduction

- Durable polypropylene loudspeaker cone

- Optimized low-frequency performance

- Effective frequency range from 45 to 150 Hz

- Second-order low-pass crossover network

- Integrated overload protection

- Rated output power up to 60 W

- Compatible with 70 V and 100 V systems

- Direct 8-ohm operation available

- Front-baffle power tap selector

- Selectable 60, 30 and 15 W power settings

- Additional 7.5 W setting for 70 V systems

- Integrated output-power matching transformer

- Maximum sound pressure level of 112 dB

- Wide 180-degree conical coverage

- Integrated metal back-can enclosure

- Three-pole ceramic screw terminal block

- Suitable for loop-through wiring

- Integrated thermal safety fuse

- Maintains circuit integrity during fire conditions

- Four integrated ceiling toggle anchors

- Tile bridge and C-ring included

- Suitable for ceilings from 4 to 25 mm thick

- Circular ceiling cut-out template included

- Circular white steel grille

- Designed for Bosch LC2 Premium-sound loudspeakers

- Suitable for voice-alarm systems

- Compliant with BS 5839-8 and EN 60849

- European CE certified

- Supplied as a two-piece set

Specifications

- Brand: Bosch

- Model: LC2-PC60G6-10

- Product type: Flush-mounted ceiling subwoofer

- Maximum power: 100 W

- Rated power: 60 / 30 / 15 W

- 70 V power settings: 60 / 30 / 15 / 7.5 W

- Rated voltage: 70 V or 100 V

- Rated impedance: 83 / 167 / 8 ohms

- Sound pressure level at 60 W: 112 dB SPL

- Sensitivity at 1 W: 94 dB SPL

- Acoustic measurement: 70 Hz at 1 m

- Effective frequency range: 45 Hz to 150 Hz

- Conical coverage angle: 180°

- Low-frequency transducer: 254 mm, 10 inches

- Cone material: Polypropylene

- Crossover: Second-order low-pass network

- Connector: Three-pole ceramic screw terminal block

- External diameter: 350 mm

- Maximum depth: 303 mm

- Mounting cut-out: 322 mm + 5 mm

- Compatible ceiling thickness: 4 to 25 mm

- Front-baffle material: ABS UL94V0

- Back-can material: Zinc-plated steel

- Grille material: Powder-coated steel

- Color: White RAL 9010

- Weight: 7 kg

- Operating temperature: -25 °C to +55 °C

- Storage temperature: -40 °C to +70 °C

- Relative humidity: Less than 95%

- Safety standard: EN 60065

- Emergency standards: BS 5839-8 / EN 60849

- Certification: CE

- Packaging: Set of 2 ceiling subwoofers

- Included accessories: Cut-out template, tile bridge, C-ring, paint shield and installation instructions
