B&C DE750TN Compression Driver 1.4″ 16 Ω – 220 W Continuous, 109 dB, Titanium Diaphragm

B&C DE750TN Compression Driver 1.4″ 16 Ω – 220 W Continuous, 109 dB, Titanium Diaphragm

Availability:
B&C Speakers
DE780TNXXX

- 220 W continuous power

- Compact 1.4″ throat exit

- 75 mm aluminum voice coil

- 500 Hz – 18 kHz frequency range

- High 109 dB sensitivity

Hurry! only 10 items left in stock.
$427.69
Quantity

Add to Compare
Add to Wishlist
Availability product:
Full Stock
  Warranty & Security

Music Plus Warranty: 1-Year Coverage for Manufacturing Defects!

  Shipping Policy

Enjoy fast, reliable, and fully tracked delivery straight to your doorstep!

  Politique retours

Easy returns. Hassle-free exchanges. Total peace of mind.

B&C DE750TN Compression Driver 1.4″ 16 Ω – 220 W Continuous, 109 dB, Titanium Diaphragm

Informations

The B&C DE750TN (16 Ω) is a premium HF compression driver designed for professional audio systems requiring high fidelity in a compact form factor. Featuring a robust 75 mm aluminum voice coil, a titanium diaphragm, and a copper shorting cap, it delivers high power handling, clarity, and extended high-frequency response.

Characteristics

- 220 W continuous (program) power handling

- 1.4″ (50 mm) throat exit

- 75 mm (3″) aluminum voice coil

- Titanium diaphragm

- Frequency response: 500 Hz – 18 kHz

- Sensitivity: 109 dB

- Copper shorting cap for extended HF response

Specifications

- Nominal impedance: 16 Ω; Minimum impedance: 11.3 Ω

- RMS power handling: 110 W; Continuous (program) power: 220 W

- Frequency range: 0.5 kHz – 18 kHz

- Recommended crossover: ≥ 0.8 kHz

- Inductance: 0.14 mH

- Flux density: 1.9 T

- Overall diameter: 180 mm (7.1″); Depth: 87 mm (3.4″)

- Net weight: 6.1 kg (13.45 lb); Shipping weight: 6.36 kg

- Mounting: 4 × M6 holes on 102 mm bolt circle
